Technical Parameters(remote control)

1    Power supply: AAA battery * 3pcs

2    Cover material:ABS

3    Fabrication processing: multicolour printing & UV varnish

 Technical Parameters(controller)

1    Working voltage: DC12V/24V

2    Output control: 2 circuits

3    Control current:6A/circuit

4    Connecting mathod: common anode

5    Dimension: L85*W64*H24

6    Receiving range:20meters

Functions of Keys

1    Key 1: medium brightness

2    Key 2: on

3    Key 3:off

4    Key 4:highest brightnessKey

5    Key 5:lowest brightness

 How to use

1. Use your finger to touch the color ring ,you can change the brightness from the highest to the lowest (100%-1%,50 grades to adjust).

2. Resume function. The previous settings will be resumed while power on again

3. Matching code Press Key

4 once within 3 seconds when power on again, the light will blink 3 times if matching is successful
